What are the different Alpha Taps for?

What are the different Alpha Taps for?


HSS Taps

• Alpha HSS Hand Taps are precision manufactured in Europe to ISO529 standards.

  • HSS Hand Taps are general purpose taps suitable for hand and machine operation,
    and are suitable for production use.
  • 2N Tolerance for optimum thread fit that balances fastener performance, manufacturing,
    economy and convenience.
  • Suitable for use in Steel, Aluminium, Copper, Brass etc.
  • Always use lubricant.
  • Alpha TAPER Taps

    Alpha Taper Taps have a lead of eight threads and are used as a starting tap in difficult
    or high precision holes.

    Alpha Taper taps can be identified by the single ring on the shaft near the driving square.



    Alpha INTERMEDIATE Taps

    Alpha Intermediate Taps have a lead of four threads and are used in most general purpose applications.

    Alpha Intermediate taps can be identified by the two rings on the shaft near the driving square.



    Alpha BOTTOMING Taps

    Alpha Bottoming Taps have a lead of two threads and are used when tapping blind holes.
    Usually preceded by a taper or intermediate tap.

    Alpha bottoming taps can be identified by their plain shaft, they have no rings on the shaft
    near the driving square.



    Alpha Hand Taps

    Alpha Hand Taps are for general purpose applications such as production tapping
    or hand tapping operations.

    Taper, plug and bottoming styles provide versatility in tough materials, blind
    and through holes. The most accurate holes require a taper (top), Intermediate (middle)
    and a bottoming (bottom) tap to create a perfect finish.



    Alpha Spiral Point Taps

    Alpha Spiral Point Taps have the same general physical dimensions as standard hand taps.

    However, the Spiral Point Tap has the cutting face of the first few threads cut at a predetermined
    angle relative to the tap's axis angle to force the evacuation of chips ahead of the cutting action.
    This feature, plus the excellent shearing action of the flute, make spiral point taps ideal for
    production tapping of through holes. Typically, this type of tap has a shallower flute passage
    than conventional taps. This gives the spiral point tap more cross-sectional area,
    which means great strength, allows higher tapping speeds, and requires less power to drive.

    The spiral point taps are also referred to as gun taps.



    Alpha Spiral Fluted Tap

    Alpha Spiral Flute Taps feature spiral flute design rather than conventional straight flutes.

    The spiral fluting feature aids in evacuating chips out of the tapped hole. Spiral flute taps
    are ideal for hard materials or in blind hole where the swarf needs to be drawn out.

    31st May 2023 Trucut NZ
